CloudView NMS Features

  • Hierarchical maps system: complete end-to-end network view and inventory (Google Maps are supported).
  • Possibility to define "logical views" for group of devices in addition to "geographical" views.
  • 24 x 7 performance and availability monitoring at multiple levels: network/map/submap/device/interface/port.
  • Scalable to virtually unlimited number of network nodes (CloudView NMS server still can be simple desktop PC).
  • Auto-discovery (via several standard protocols).
  • "Top 10" feature allows to report most used or most faulty ports/interfaces in large networks.
  • Historical reports (up to 3 months) of  real ports/interfaces rates/utilization. Other historical data displayed in graphs.
  • Graphical links representation and link status background monitoring.
  • Monitoring fiber network infrastructure using OTDR (Optical Time Domain Reflectometer) data to pinpoint the exact place
    (address) fiber repairing crew should be sent. See example  for Optical Zonu devices. New!
  • Capability to manage / monitor any vendor SNMP or TCP/IP compliant devices.
  • IT Automation engine, e.g.: some predefined CLI command/script can be executed periodically on the monitored server and,
    depending of the output pattern, some action (e-mail/SMS/sound, running shell script…) can be performed.
  • Capability to compile any vendor private SNMP MIBs and create corresponding custom devices types. GUI Capability to build
    custom MIB monitoring applications and assign it  to 3rd party devices. SNMP MIB Browser included.
  • Capability to create unlimited number of SNMP probes even without compiling your MIBs (using "raw" SNMP OIDs).
  • Client-server multi-user system with multiple user profiles. Optional capability to use MS Windows Authentication and profiles.
  • Rich and friendly GUI available to simultaneous users both locally (at the server) and via remote secure HTML-5 web-based
    console.  All modern browsers including  mobile devices (Android, iPad/iPhone, Windows) phone are supported. See
    CloudView NMS Android phone/tablet Web App  and  iPhone/iPad Client Web App ). Optional multi-platform
    (Windows/Linux/Mac)  full-blown GUI client is also available,
  • Security: encryption, password system, remote access protocols  correspond to FIPS and requirements of US Department of
    Defense. Configurable 2-factors authentication for remote login.
  • All SNMP versions supported (SNMPv1, SNMPv2, and SNMPv3 /including AES256 privacy protocol support/)
  • CoudView NMS server is supported on all modern OS platforms including Windows,  Linux, Mac OS, Solaris and Raspberry Pi.
  • Embedded Telnet/Telnet over SSL/SSH/TL-1 configuration and monitoring for non-SNMP compliant devices
  • "Proxy SSH" function turns CloudView NMS Server in a kind of "SSH-enabled terminal server". It creates secure channel for
    service providers to access their customer's SSH-devices over public Internet without VPN or port forwarding.
  • Both IPv4 and IPv6 supported.
  • TFTP client and server included; sysLog client  and server included
  • MTConnect support per standard (http://www.mtconnect.org), for factory/shop floor  devices monitoring.
  • Environmental Monitoring Application (temperature, humidity...) based on Geist  ITWatchDogs "WATCHDOG 15" sensors
    or/and Raspberry Pi with connected DS18B20 thermometer. For example, when a server room temperature is too high, the
    system    can automatically SSH-login in every server to "poweroff" it. Thousands of sensors/servers can be supported.
  • GUI support for many standard  SNMP MIBs: MIB-2,  RMON-MIB, BRIDGE-MIB,  HOST-MIB, Routing MIBs....This allows to
    manage multi-vendor, heterogeneous networks to monitor per-ports traffic, CPUs load with thresholds alerts, software
    inventory report, etc.... We checked devices from multiple vendors, including Cisco, Extreme, MikroTik, Alcatel...
  • Included special support for Cisco SNMP agents and MS Windows SNMP agents.
  • Email/SMS alerts of events/alarms and/or SNMP Traps with customized filters.
  • Alarms/Events history is kept in standard SQL Database (MariaDB Server is installed with CloudView). Allows viewing / reporting
    alarms per submap/device/port/interface  for last hour, day, week, month,...etc
  • Capability to send all the CloudView NMS events to Windows Event Log. Capability to monitor Windows Event Log on remote
    computers either via SNMP or via CloudView NMS Agent.
  • Capability to forward all the alarms to other NMS/OSS as SNMP Traps, TL-1 asynchronous messages, sysLog messages.
  • Current Alarms Log (vs. History Alarms Log) shows only current problems. Sophisticated alarms correlation algorithm is used.
  • Alarms Clear and Alarms Acknowledgement features allow to keep record of which user/operator was dealing with any particular
    alarm.
  • Backup/restore functions of all the maps/devices/alarms/settings
  • Automatic periodical scan of predefined IP ranges for devices to appear/disappear. This feature can alert network administrators
    about newly hooked up devices.
  • Powerful event monitoring with configurable alarm actions, scripts and  sounds notification. IT Automation features.
  • Capability to auto-discover and monitor performance of mission-critical Layer-7 network services, such as e-mail, FTP, HTTP,
    etc...
  • TL1 Northbound interface, TL1 gateway and TL1-SNMP translation software for any SNMP capable device, TL1 proxy.
  • XML Northbound interface, XML-SNMP translation engine for any SNMP capable device, XML proxy, RESTful API.
  • SNMP Northbound interface, CloudView comes with its own SNMP Agent and supported private MIB.
  • Carriers / Service Providers features: Service Monitoring, SLA calculation reports, Customers self monitoring portals..
  • Device/NMS Actions scheduler feature allows to schedule important device/network maintenance operations.
  • Distributed management model: one CloudView server (Master) can monitor another CloudView server (Slave) and access all
    its info. Service Provider (MSP) can drop pre-configured "headless" (no keyboard/monitor) Slave box (Linux/Windows) in
    customer's network and securely (over SSL) monitor all remote locations (see here) from "Central Office"  unified console.
    Cloud service, like (VoIP) can be monitored along the path from customers remote location (see here). No need to reconfigure
    customer's router. The "on-premises" Slave-box can be as small and cheap as Raspberry Pi Linux box ($35.00). See here.
  • Capability to run CloudView server as Windows service or Linux/Unix boot daemon.
  • Special app for monitoring web sites performance and response time. Also websites can be monitored for changes.
  • Optional CloudView Agent can be installed on managed devices/computers even when they are hidden behind a firewall or NAT
    IP Addresses (Private IP Addresses) mechanism. It provides convenient way to get/put files  from/to managed computers. When
    running on Windows or Linux, it allows to monitor CPU, RAM, Bandwidth and File Systems usage. User can set thresholds on
    the above resources  usage and receive corresponding events in the Events Log and as e-mails.
  • CloudView Agent for Android phones/tablets allows companies to implement BYOD ("Bring Your Own Device") system and
    MDM (Mobile Devices Management) within CloudView NMS. It also allows monitoring thousands of Android-based sales PDAs
    for battery power left, WiFi level, storage left,  geolocation, ... etc.
  • CloudView Android Agent provides support for Android phones/tablets "paired" with "SensorTag TI"  (Texas Instruments
    SimpleLink Bluetooth® Smart SensorTag Bluetooth Low Energy) and PebbleBee Bluetooth Low Energy devices. Additionally
    there is support for iBeacon devices  (up/down/"show distance" )
  • Support for Dataprobe COE-8O Contact Closure unit to provide dry contacts set in response to events/alarms.  Support for
    Tait Communications "TB9100" device
  • Support for Optical Zonu https://www.opticalzonu.com devices
  • Voice Server (VOIP) comes as a part of CloudView NMS package. NMS Users (and not only) can now talk to each other using
    CloudView NMS Server as VOIP (voice over IP) Server. Simply point you browser to special URL and securely talk to your peers
    around the world New!
CloudView NMS Features
Please see also our FAQ (Frequently Asked Questions) page which illustrates some of the above features with screenshots.
